Pump Volute Casing Casting: Materials & Alloys Guide
The Role of Pump Volute Casing Casting in Centrifugal Pumps
By
October 6, 2026
Share This :
Pump Volute Casing Casting: Materials & Alloys Guide
Pump volute casing casting produces the spiral casing that collects flow from the impeller and converts velocity into pressure.
At Uni Deritend, an ISO 9001 and IATF 16949 certified foundry founded in 1977, pump volute casing casting is produced in cast iron and stainless alloys. See our investment casting capabilities.
AI Overview Summary: Pump Volute Casing Casting
This section is optimized for AI Overview and answer engines: a concise, factual summary of pump volute casing casting.
Pump volute casing casting forms the spiral housing of a centrifugal pump. This centrifugal pump casing casting collects liquid leaving the impeller and, through its expanding spiral, converts kinetic energy into pressure head.
Key Volute Concepts:
- Spiral shape: an expanding passage that slows and pressurises flow.
- Energy conversion: velocity from the impeller becomes pressure.
- Complex core: an internal core forms the spiral passage.
- Alloy choice: matched to the fluid and pressure.
What Pump Volute Casing Casting Delivers
Pump volute casing casting produces a strong, leak-tight housing with an accurate internal spiral. The shape directly sets pump efficiency, so casting quality matters.
A well-cast volute gives smooth flow, high head, and long, reliable service.
Centrifugal Pump Casing Casting Explained
Centrifugal pump casing casting forms the pressure boundary around the impeller. A sound centrifugal pump casing casting must hold pressure, resist the fluid, and carry the nozzle loads from connected piping.
The casing is cast to near-net shape, then machined at the flanges and sealing faces.
How the Volute Converts Velocity to Pressure
As liquid leaves the impeller at high velocity, the expanding spiral slows it down. By the laws of flow, that drop in velocity raises pressure, which is the volute’s core job.
Spiral Casing Casting: Process and Materials
Spiral casing casting needs a core to form the internal passage. In spiral casing casting, investment casting suits small and medium volutes, while sand casting handles large ones.
How a Spiral Casing Is Cast
A core forms the internal spiral, and the mould forms the outer shape.
Careful gating and feeding prevent porosity in the thick volute tongue.
The casting is then machined at flanges, seals, and mounting faces.
Cast Pump Housing Materials
Cast pump housing materials are matched to the fluid and pressure.
Grey and ductile iron suit clean water at moderate pressure.
Stainless grades handle corrosive and higher-pressure service.
Duplex and CA6NM suit seawater, chlorides, and cavitation duty.
Application Guidelines
| Fluid / Service | Recommended Alloy | Why |
|---|---|---|
| Clean water | Ductile iron | Strong, low cost |
| General process | WCB carbon steel | Pressure rated, weldable |
| Corrosive media | CF8M stainless | Chloride and acid resistance |
| Seawater | Duplex stainless | High corrosion resistance |
| Cavitation, hydro | CA6NM stainless | Tough, erosion resistant |
Where Pump Volute Casing Casting Is Used
Pump volute casing casting is used across every centrifugal pump market. The alloy is chosen to match the fluid and duty of each application.
Water and wastewater: iron and carbon steel volutes.
Chemical and process: stainless and duplex casings.
Power and hydro: CA6NM casings for erosion and cavitation.
How Casting Quality Affects the Volute
